IFM Electronic CR0401 - Functions and Features; 3�1 Overview of the Common Characteristics; 3�2 Application Example

BasicController / BasicController
plus
6
3 Functions and features
The freely programmable controllers of the "BasicController" and
"BasicController
plus
" series are rated for use under difficult conditions (e�g�
extended temperature range, strong vibration, intensive EMC interference)� They
are suitable for direct installation in mobile vehicles�
By means of the application software the user can configure the inputs and
outputs to adapt to the respective application� The controllers can be used as CAN
controller, CANopen master or intelligent I/O module. (→ 8 Technical data).
Application-specific extensions and adaptations are possible in conjunction with
additional products of the modular Basic series�
WARNING
The "BasicController" and "BasicController
plus
" series are not approved for safety
tasks in the field of safety of persons�
NOTE
"BasicController" and "BasicController
plus
" are intended for installation in vehicle
bodies, not in engines�
3.1 Overview of the common characteristics
● Freely programmable to IEC 61131-3
● 2 CAN interfaces (incl� interface for BasicDisplay CR0451 or CR0452)
● Configurable inputs/outputs
● Protection IP 20 (with cover and cable seal IP 54)
● Status LED
3.2 Application example
Use with cover and BasicDisplay
