9
UK
Voltage output 0 ��� 10 V (example volumetric flow monitoring)
Factory setting Measuring range scaled
MEW = final value of the measuring range
In the set measuring range the output signal is between 0 and 10 V�
It is also indicated:
Volumetric flow above the measuring range: output signal > 10 V�
Current output 4 ��� 20 mA (example volumetric flow monitoring)
Factory setting Measuring range scaled
MEW = final value of the measuring range
In the set measuring range the output signal is between 4 and 20 mA�
It is also indicated:
Volumetric flow above the measuring range: output signal > 20 mA�
