8.2 Explanation of the menu
SP1/rP1 Upper / lower limit value for system temperature at which OUT1 switches.
SP2/rP2 Upper / lower limit value for system temperature at which OUT2 switches.
OU1 Output function for OUT1:
Switching signal for the temperature limit values: Hysteresis function [H ..] or
window function [F ..], either normally open [. no] or normally closed [. nc].
OU2 Output function for OUT2:
Switching signal for the temperature limit values: Hysteresis function [H ..] or
window function [F ..], either normally open [. no] or normally closed [. nc].
Mmod Measurement method (2-wire, 3-wire or 4-wire temperature sensors).
EF Extended functions / opening of menu level 2.
HI Maximum value memory for system temperature.
LO Minimum value memory for system temperature.
COF Zero-point calibration.
dS1/dS2 Switch-on delay for OUT1 / OUT2
dr1/dr2 Switch-off delay for OUT1 / OUT2.
FOU1 Behaviour of output 1 in case of an internal fault.
FOU2 Behaviour of output 2 in case of an internal fault.
P-n Output logic: pnp / npn.
diS Update rate and orientation of the display.
Uni Unit of measurement for system temperature.
rES Restore factory settings.
