ifm Programming Manual BasicDisplay CR0452 v03.02 05 / 2018
Configurations Set up the runtime system
>
4.1.1 Reinstall the runtime system
14635
8486
On delivery of the ecomatmobile controller no runtime system is normally loaded (LED flashes green
at 5 Hz). Only the boot loader is active in this operating mode. It provides the minimum functions for
loading the operating system (e.g. RS232, CAN).
Normally it is necessary to download the runtime system only once. The application program can then
be loaded to the device (also several times) without influencing the runtime system.
The runtime system is provided with this documentation on a separate data carrier. In addition, the
current version can be downloaded from the website of ifm electronic gmbh:
→ www.ifm.com
8651
Risk of data loss!
In case of power failure during the data transmission data can be lost so that the device is no longer
functionable. Repair is only possible by ifm electronic.
► Ensure an uninterrupted power supply during the data transmission!
8485
The software versions suitable for the selected target must always be used:
• runtime system (ifm_CR0452_Vxxyyzz.RESX),
• PLC configuration (ifm_CR0452_Vxx.CFG),
• device library (ifm_CR0452_Vxxyyzz.LIB ) and
• the further files.
V
xx: 00...99
yy: 00...99
zz: 00...99
version
target version number
release number
patch number
The basic file name (e.g. "CR0452") and the software version number "xx" (e.g. "01") must always have
the same value! Otherwise the device goes to the STOP mode.
The values for "yy" (release number) and "zz" (patch number) do not have to match.
4368
The following files must also be loaded:
• the internal libraries (created in IEC 1131) required for the project,
• the configuration files (*.CFG) and
• the target files (*.TRG).
It may happen that the target system cannot or only partly be programmed with your currently
installed version of CODESYS. In such a case, please contact the technical support department of ifm
electronic gmbh.
Contact → www.ifm.com
The runtime system is transferred to the device using the separate program "Maintenance Tool". (The
program can be downloaded from ifm's website, if necessary):
→ www.ifm.com
Normally the application program is loaded to the device via the programming system. But it can also
be loaded using the "Maintenance Tool" if it was first read from the device.
