Ifor Williams Trailers TT3621 - Tiltbed TB Model Data

Page | 54
Electric Tip
40 kg
Electric Winch
55 kg
Headboard only
28 kg
31 kg
N/A
Ladder Rack
20 kg
24 kg
N/A
Full Drop side Kit incl. headboard
121 kg
124 kg
N/A
Mesh Side Extensions
125 kg
130 kg
N/A
High Ramp
+33 kg
+40 kg
N/A
Floor lashing rings (per pair)
1 kg
N/A
Centre Decking
N/A
39 kg
Ski-Jump
N/A
106 kg
8.4 Tiltbed – TB
Type
TB4021 -
302
TB4021 -
352
TB4621 -
302
TB4621 -
352
TB5021 -
352
TB5021 -
353
TB5521 -
353
Unladen Weight (A
ramp or Skid option
must be added)
685 kg
730 kg
735 kg
785 kg
835 kg
860 kg
900 kg
Gross Weight
3000 kg
3500 kg
3000 kg
3500 kg
3500 kg
3500
kg
3500 kg
Tilting Capacity
≤2315 kg
≤2770 kg
≤2265
kg
≤2715 kg
≤2665 kg
≤2640 kg
≤2600 kg
No. of Axles
2
2
2
2
2
3
3
Maximum imposed load
150 kg
150 kg
150 kg
150 kg
150 kg
150 kg
150 kg
Loading
platform
dimensions
Length
4.07m
4.07m
4.64m
4.64m
5.1m
5.1m
5.57m
Width
2.04m
2.04m
2.04m
2.04m
2.04m
2.04m
2.04m
Tilt Angle
11°
13.5°
10.5°
12.5°
10°
11°
9.5°
Hydraulic
tip system
Manual
P11415 - standard
Electric
P11976 - option
Option
Additional Unladen Weight
Headboard, Dropsides,
Mesh Ramp
160 kg
170 kg
180 kg
190 kg
Mesh Ramp
80 kg
Hinged Mesh Skids
45 kg
Removable Skids
40 kg
Ladder Rack
14 kg
Headboard
25 kg
Wheel Chock Kit
9 kg
Winch Mounting
Bracket Kit
19 kg
Battery Carrier (only)
9 kg
Battery and Battery
Carrier
35 kg
