Page | 52
trailer during
normal braking.
All
Trailer locks and
releases wheels
under normal or
hard breaking.
Coupling Damper may be
worn out.
Carry out Coupling Damper
check as described in section
6.8.3.1. Replace if necessary.
All
Rattle from
Coupling when
Towing
Either the tow-ball is worn,
or the coupling head is
worn
or the load is too far to the
rear of the trailer resulting
in insufficient imposed
load.
Check tow-bar and coupling for
excessive looseness when
unladen. Check imposed load
and adjust load position if
necessary.
7 – End of Life Disposal
All the trailers covered by this manual contain materials requiring disposal at an appropriate
recycling facility:
Hydraulic Oil (All trailers)
Batteries (Only trailers with electric pump or winch)
8 – Technical Data
8.1 All Versions
Hydraulic System
Manual Pump
Hydraulic system
Electric Pump
Combined Hydraulic & Electrical system
Noise Emission
˂ 70dBA
Battery
12V 105Ah
Maximum allowable
working pressure
210 Bar
Pressure relief valve
setting
180 Bar
Oil reservoir capacity
– Manual Tilt
4 Litre
Oil reservoir capacity
– Manual Tipper
6 Litre
Oil reservoir capacity
– Electric all
7 Litre
Hydraulic Oil
Specification
See section 6.2
Operating Conditions
Snow and ice to sand and dust but not immersed
