User manual Elbawww.igloo.pl
Fig.1 Construction of the device 10
Fig.2 Mounting perforated shelves 11
Fig.3 Control panel 11
Fig.4 Temperature sensor inside the cabinet 13
Fig.5 Exchange of fl uorescent lamps 13
Fig.6 Cleaning of the condenser 13
Fig.7 Data plate 15
Fig.8 „Igloo” thermostat control panel 16
1. UNLOADING
The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.
2. PROPERTIES OF THE DEVICE
2.1. Purpose
”ELBA” is a universal device used to display and store various deep frozen products. “Elba” device is used in gastronomy
entities, confectioneries, coffee houses and store chains. Guaranteed temperature within the cabinet ranges between
-18ºC and -12ºC with ambient temperature ranging between +15ºC and +25ºC and relative air humidity of up to 60%.
2.2. Description of the device
”ELBA” is a freezing cabinet with internal upper aggregate and forced air circulation. The cabinet is equipped with auto-
matic defrosting, automatic condensate evaporation and electronic thermostat optionally cooperating with temperature
recording module enabling to record and signal too low and too high temperature within the device. ”ELBA” has glazed,
divided door. Door glasses are made of special, heated composite glass. The cabinet is equipped with 6 grid plastifi ed
shelves with layout regulation. Each shelf is equipped with price strip. Our devices are made according to modern techno-
logies and have all certifi cates required by law.
This sign signifi es information of particular meaning for user security and for proper device
exploitation.
Contents List of Figures
List of tables
Table 1 Technical data 10
User manual
1. UNLOADING 9
2. PROPERTIES OF THE DEVICE 9
2.1. Purpose 9
2.2. Description of the device 9
2.3. Technical data 10
3. PREPARING THE DEVICE FOR EXPLOITATION 10
3.1. Requirements concerning the place of installation 10
3.2. Connection and actuation 11
4. EXPLOITATION 11
4.1. Temperature regulation 12
5. MAINTENANCE 12
5.1. Cleaning and maintenance 12
6. SERVICE 14
6.1. Fault identifi cation and repair 14
6.2. SERVICE 15
7. THERMOSTAT SERVICE 16
7.1. “IGLOO” thermostat 16
en
ELBA
