1. UNLOADING
The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.
2. PROPERTIES OF THE DEVICE
2.1. Purpose
MAX is a universal cooling device used to store and display a wide assortment of grocery products in singular packages,
previously cooled to storage temperature. Our display cabinets ensure universal and efcient display area for all types of
commercial and gastronomic units. Guaranteed temperature inside the display cabinet equals +2ºC/+8ºC with ambient
temperature of +15ºC/+25ºC and relative air humidity of up to 60%.
2.2. Description of the device
MAX cases have static cooling. MAX display cabinets have dynamic or static cooling. All types are equipped with automa-
tic defrosting and electronic thermostat optionally cooperating with temperature recording module enabling to record and
signal too low and too high temperature within the device. There is also an option with automatic condensate evaporation.
“MAX” display cabinet is available in stationary or moving version. Our devices are made according to modern technolo-
gies and have all certicates required by law.
