User manual MAX www.igloo.pl
6.2. SERVICE
If after checking points described in chapter 6.1 „Fault identication and repair” the device still does not work properly, please
contact Technical Service of the Igloo company, stating the data from the data plate Fig.6 (p.16):
• Serial number (NS)
• Production date
• Type (name of the device)
and
• Date when the device was purchased
• Description of the problem
• Your exact address and telephone number (with the code number)
Data plate is placed at the back of the device, in the right upper cor-
ner below the top Fig.1/18 (p.11)
Fig.6 Data plate
The above gure shows a demonstrative data plate and the data stated on the plate are exemplary
data, which are not related with “MAX” device!
21 3 4 65
7. THERMOSTAT SERVICE
7.1. „IGLOO” thermostat
Fig.7 „Igloo” thermostat control panel
1 – Cooling on/off switch
2 – Manual defrosting switch
3 – Aggregate and defrosting operating control diode
4 – Temperature monitoring switch on defrosting sensor
5 – Temperature regulation switch (increase)
6 – Temperature regulation switch (decrease)
