Igloohome Deadbolt 2S - Installation Guide; Requirements

6
Installation Guide
145mm (5.70”)
160mm (6.29”)
Requirements
Measurements
35mm (1.37”) to 60mm (2.36”)
10mm (0.39”)
20mm (0.78”)
>110mm (4.33”) for 60mm (2.36”) / >120mm (4.72”) for 70mm (2.75”) backset
50mm (1.96”)
a
b
c
d
e
a
b
b
b
c
e
d
Clearance
Door Thickness
