25www.iGOelectric.com
BRAKE MAINTENANCE FOR TEKTRO
AURIGA HYDRAULIC DISC BRAKE
CHANGING BRAKE PADS TEKTRO PART # E10.11
• Using a 5mm allen key remove caliper mounting
bolts & remove caliper (gure 25.1).
• Choose a mid-size at head screw driver and
wipe blade with rubbing alcohol.
• Insert at head between brake pads & push
pads to the outside position.
• Using a 5 mm allen key loosen the pad
mounting bolt as shown in gure 25.2.
• Remove pads holder and replace with only
genuine Tektro brake pads Part # E10.11.
• Insert holder with new pads and tighten pad mounting bolt.
• Mount caliper and align by following instructions.
• Check alignment of caliper and if needed follow
instructions above on brake caliper alignment.
CAUTION! Only use mineral oil, do not use DOT oil.
Fig. 25.1 Fig. 25.2
