FRONT PANEL CONTROL
Menu / Input Select shortcut keys ( )*1
Scroll Down / Brightness/Contrast/ACR/ECO Mode shortcut keys(
)
Scroll Up / OptiColor Mode (
)*4
Select / Input select ( )
Power Indicator
Blue: Normal operation
The monitor enters into power management mode which reduces
the power consumption to less than 1W when receiving no horizontal and/
or vertical sync signal.
Power Switch ( )
AC Connector (Power IN)
DVI-D 24Pin Connector (DVI)
HDMI Connector (HDMI)*2
D-SUB mini 15pin Connector (VGA)
Audio Connector (AUDIO IN)
Keyhole for Security Lock *3
Speakers
CONTROLS AND CONNECTORS
*1 Input Select shortcut keys is available under no signal input.
*2
Available for ProLite E2407HDS-B1/W1 only.
You can fasten a security lock and cable to prevent the monitor from being removed
NOTE
6 BEFORE YOU OPERATE THE MONITOR
*4 OptiColor Mode: Press the
Button when the Menu is not displayed.
