Iiyama ProLite TE8612MIS User Manual

ENGLISH
12 BEFORE YOU OPERATE THE MONITOR
Turn the monitor ON and OFF.
Number(1-9)/
Other /
Function(F1-
F12)
Under iiWare: 0-9 numeric input
Under Windows: 0-9 numeric input,
Start/Space/ALT+Tab/ALT+F4/F1-12
for Keyboard function
Display
Provide source and resolution
information.
Home Android system main screen button.
Input Select the source.
Green Lock and unlock Buttons function.
Red
Lock and unlock Buttons and Touch
function.
ScreenO󰀨 TurnthebacklightOnandO󰀨.
Navigate through submenus and
settings.
: Up Button
: Down Button
: Left Button
: Right Button
Enter
Conrmyourselectionorsave
changes.
Quickly start “Writing Software”.
PgUp / PgDn
WhenselectFile:Therst/Last
When Internet browser: Scroll Up /
Scroll Down
Not available on this model.
Turnonoro󰀨themutefunction
when the Menu is not displayed.
MENU
Display the “Screen Setting“ menu
when the Android system is not
displayed.
Yellow Lock and unlock Touch function.
Blue Freeze the picture.
Backspace
Back
Return to a previous menu or closes
the OSD Menu.
VOL+ / VOL-
VOL+: Increase the sound volume.
VOL-: Decrease the sound volume.
FUNCTIONS OF THE REMOTE CONTROL

Iiyama ProLite TE8612MIS Specifications

General

Haze rate	28 %
Panel life	50000 h
Pixel pitch	0.4935 x 0.4935 mm
Response time	8 ms
Display diagonal	86 \
Surface hardness	7H
Display brightness	400 cd/m²
Display technology	LED
Number of displays	1
Native aspect ratio	16:9
Horizontal scan range	30 - 135 kHz
LED backlighting type	Direct-LED
Touchscreen technology	Infrared
Display number of colors	1.073 billion colors
Display diagonal (metric)	217.4 cm
Active display area (W x H)	1895 x 1066 mm
Number of simultaneous touchpoints	40
Orientation	Horizontal
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	16.5 mm
Placement supported	Indoor
Bezel width (bottom)	31 mm
Positioning accuracy	1.5 mm
Panel mounting interface	800 x 600 mm
Bluetooth version	5.0
Power supply type	Internal
Internal memory	32 GB
Processor cores	4
Internal storage capacity	4 GB
Operating system installed	Android 11
On-board graphics card model	ARM Mali-G52
DVI port	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB connector type	USB Type-C
USB ports quantity	6
HDMI input ports quantity	3
Ethernet LAN (RJ-45) ports	2
RMS rated power	32 W
Purpose	Commercial
HDCP version	2.2
Number of OSD languages	9
Operating hours (hours/days)	16/7
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, ITA, POL, RUS
Sustainability certificates	RoHS, WEEE
Cables included	AC, HDMI, USB
Base material	Metal
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	215 W
Package depth	225 mm
Package width	2110 mm
Package height	1283 mm
Package weight	75900 g

Weight and Dimensions

Display depth	100 mm
Display width	1957 mm
Display height	1160 mm
Display weight	58600 g
