Iiyama ProLite TE8612MIS User Manual

ENGLISH
18 BEFORE YOU OPERATE THE MONITOR
CONNECTING YOUR MONITOR
Ensurethatboththecomputerandthemonitorareswitchedo󰀨.
Connect the computer to the monitor with the signal cable.
Connect the computer to the monitor with the Touch USB Cable.
Connect the computer to the monitor with the USB Type-C Cable when viewing images on your
monitor through the USB Type-C Connector or when using the monitor’s USB hub function.*
ConnectthePowerCabletothemonitorrstandthentothepowersource.
Turnonyourmonitor(MainPowerSwitchandPowerButton)andcomputer.
*

When charging connected device via USB Type-C Connector, check if the device is equipped
with aUSBType-CConnectorthatsupportschargingfunctionviaUSBPD(=PowerDelivery).

The connected device can be charged via USB Type-C Connector even when the monitor is in
standby mode.

The USB power delivery is up to 65W. If the connected device required more than 65W for
  operationorforbootup(whenthebatteryisdrained),usetheoriginalpoweradapterthatcame
with the device.

IfaseparatelypurchasedUSBType-CCableisused,makesurethecableiscertiedbyUSB-IF
and is full-featured with power delivery and video / audio / data transfer functions.

USB C to A cable is not included with the monitor. If you use a USB C to A cable, please note
that you can only transfer data.

Compatibilitywithallconnecteddevicesisnotguaranteedduetodi󰀨erentuserenvironments.

Make sure that the building installation has a circuit breaker of 120/240V, 20A
(maximum).

The signal cables used for connecting the computer and monitor may vary with the
type of computer used. An incorrect connection may cause serious damage to both
the monitor and the computer. The cable supplied with the monitor is for a standard
connector. If a special cable is required please contact your local iiyama dealer or
regionaliiyamao󰀩ce.

MakesureyoutightenthengerscrewsateachendoftheSignalCable.

The touch function is ready for use about 5 seconds after connecting the USB cable and
canbeoperatedwithapen,ngeroranyotherpointer.

The Class I pluggable equipment Type A must be connected to protective earth.

The socket-outlet shall be installed near the equipment and shall be easily accessible.

Excessive sound pressure from ear-/headphones can cause hearing damage/hearing loss.
NOTE

Iiyama ProLite TE8612MIS Specifications

General

Haze rate	28 %
Panel life	50000 h
Pixel pitch	0.4935 x 0.4935 mm
Response time	8 ms
Display diagonal	86 \
Surface hardness	7H
Display brightness	400 cd/m²
Display technology	LED
Number of displays	1
Native aspect ratio	16:9
Horizontal scan range	30 - 135 kHz
LED backlighting type	Direct-LED
Touchscreen technology	Infrared
Display number of colors	1.073 billion colors
Display diagonal (metric)	217.4 cm
Active display area (W x H)	1895 x 1066 mm
Number of simultaneous touchpoints	40
Orientation	Horizontal
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	16.5 mm
Placement supported	Indoor
Bezel width (bottom)	31 mm
Positioning accuracy	1.5 mm
Panel mounting interface	800 x 600 mm
Bluetooth version	5.0
Power supply type	Internal
Internal memory	32 GB
Processor cores	4
Internal storage capacity	4 GB
Operating system installed	Android 11
On-board graphics card model	ARM Mali-G52
DVI port	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB connector type	USB Type-C
USB ports quantity	6
HDMI input ports quantity	3
Ethernet LAN (RJ-45) ports	2
RMS rated power	32 W
Purpose	Commercial
HDCP version	2.2
Number of OSD languages	9
Operating hours (hours/days)	16/7
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, ITA, POL, RUS
Sustainability certificates	RoHS, WEEE
Cables included	AC, HDMI, USB
Base material	Metal
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	215 W
Package depth	225 mm
Package width	2110 mm
Package height	1283 mm
Package weight	75900 g

Weight and Dimensions

Display depth	100 mm
Display width	1957 mm
Display height	1160 mm
Display weight	58600 g
