Iiyama ProLite TE8612MIS User Manual

ENGLISH
OPERATING THE MONITOR 23

The Back Button on the remote control can be used to return previous menu item.

Any changes are automatically saved in the memory when the On Screen Display disappears.
Turningo󰀨thepowershouldbeavoidedwhileusingtheMenu.

Adjustments for Image Position and Phase are saved for each signal timing. Except for these
adjustments, all other adjustments have only one setting which applies to all signal timings.
NOTE
Direct

Freeze Function:
Press the Blue button when Menu is not displayed.
Repeat successively to activate/deactivate the function.

Backlight Function:
PresstheScreenO󰀨buttonwhenMenuisnotdisplayed. 
RepeatsuccessivelytoOn/O󰀨thefunction.

Input Function:
Press the Input Button when Menu is not displayed.

Volume Function:
Press the VOL+/VOL- Buttons when Menu is not displayed.

Mute Function:
Press the Button when Menu is not displayed.
RepeatsuccessivelytoOn/O󰀨thefunction.

Kiosk Mode Function:
Disable touch functions, buttons, Menu etc.
Turno󰀨"iiWareEnable"inDebugmenu(Input+2580)
* Available for Remote Control only.
[LOCK MODE]

Front Power Button:
Press the Green Button when Menu is not displayed, will lock/unlock the Front Power Button.

Touch function:
Press the Yellow Button when Menu is not displayed, will lock/unlock the Touch function.

Front Power Button & Touch function:

Press the Red Button when Menu is not displayed, will lock/unlock the Front Power Button and
Touch function.
* Available for Remote Control only.

Iiyama ProLite TE8612MIS Specifications

General

Haze rate	28 %
Panel life	50000 h
Pixel pitch	0.4935 x 0.4935 mm
Response time	8 ms
Display diagonal	86 \
Surface hardness	7H
Display brightness	400 cd/m²
Display technology	LED
Number of displays	1
Native aspect ratio	16:9
Horizontal scan range	30 - 135 kHz
LED backlighting type	Direct-LED
Touchscreen technology	Infrared
Display number of colors	1.073 billion colors
Display diagonal (metric)	217.4 cm
Active display area (W x H)	1895 x 1066 mm
Number of simultaneous touchpoints	40
Orientation	Horizontal
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	16.5 mm
Placement supported	Indoor
Bezel width (bottom)	31 mm
Positioning accuracy	1.5 mm
Panel mounting interface	800 x 600 mm
Bluetooth version	5.0
Power supply type	Internal
Internal memory	32 GB
Processor cores	4
Internal storage capacity	4 GB
Operating system installed	Android 11
On-board graphics card model	ARM Mali-G52
DVI port	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB connector type	USB Type-C
USB ports quantity	6
HDMI input ports quantity	3
Ethernet LAN (RJ-45) ports	2
RMS rated power	32 W
Purpose	Commercial
HDCP version	2.2
Number of OSD languages	9
Operating hours (hours/days)	16/7
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, ITA, POL, RUS
Sustainability certificates	RoHS, WEEE
Cables included	AC, HDMI, USB
Base material	Metal
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	215 W
Package depth	225 mm
Package width	2110 mm
Package height	1283 mm
Package weight	75900 g

Weight and Dimensions

Display depth	100 mm
Display width	1957 mm
Display height	1160 mm
Display weight	58600 g
