ENGLISH
OPERATING THE MONITOR 45
1) Adjust the H Position so that the left side of the picture frame will move to the left edge
of the display area.
When the left side of the picture frame moves apart from the left edge of the display
areaduringtheClockadjustment,adjuststeps1)and2).
Another way to make the Clock adjustment is to correct the vertical wavy lines in the
zebra pattern.
ThepicturemayickerduringtheClock,H/VPositionadjustment.
In case the picture frame is bigger or smaller than the data display area after the
Clock adjustment, repeat steps from .
2) Stretch the right side of the picture frame to the right edge of the display area by
adjusting the Clock.
Perform the Auto Adjustment.
Adjust the image manually by following procedure below when the screen has a icker or
blur, or the picture does not t in the display area after performing the Auto Adjust.
Adjust the V Position so that the top and bottom of the picture frame will t to the display
area.
NOTE

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Iiyama ProLite TE8612MIS and is the answer not in the manual?

Iiyama ProLite TE8612MIS Specifications

General IconGeneral
Haze rate28 %
Panel life50000 h
Pixel pitch0.4935 x 0.4935 mm
Response time8 ms
Display diagonal86 \
Surface hardness7H
Display brightness400 cd/m²
Display technologyLED
Number of displays1
Native aspect ratio16:9
Horizontal scan range30 - 135 kHz
LED backlighting typeDirect-LED
Touchscreen technologyInfrared
Display number of colors1.073 billion colors
Display diagonal (metric)217.4 cm
Active display area (W x H)1895 x 1066 mm
Number of simultaneous touchpoints40
OrientationHorizontal
Product colorBlack
Product designDigital signage flat panel
Bezel width (side)16.5 mm
Placement supportedIndoor
Bezel width (bottom)31 mm
Positioning accuracy1.5 mm
Panel mounting interface800 x 600 mm
Bluetooth version5.0
Power supply typeInternal
Internal memory32 GB
Processor cores4
Internal storage capacity4 GB
Operating system installedAndroid 11
On-board graphics card modelARM Mali-G52
DVI port-
USB version2.0/3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB connector typeUSB Type-C
USB ports quantity6
HDMI input ports quantity3
Ethernet LAN (RJ-45) ports2
RMS rated power32 W
PurposeCommercial
HDCP version2.2
Number of OSD languages9
Operating hours (hours/days)16/7
On Screen Display (OSD) languagesCZE, DEU, DUT, ENG, ESP, FRE, ITA, POL, RUS
Sustainability certificatesRoHS, WEEE
Cables includedAC, HDMI, USB
Base materialMetal
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.3 W
Power consumption (standby)0.5 W
Power consumption (typical)215 W
Package depth225 mm
Package width2110 mm
Package height1283 mm
Package weight75900 g
Weight and Dimensions IconWeight and Dimensions
Display depth100 mm
Display width1957 mm
Display height1160 mm
Display weight58600 g
