ENGLISH
8 BEFORE YOU OPERATE THE MONITOR
<Back>
* Available for ProLite TH4264MIS only.
<Right Side>
RS232C OUT D-SUB 9pin
RS232C Connector
RS232C IN D-SUB 9pin
RS232C Connector
COMPONENT
VIDEO (VIDEO IN)
RCA G/B/R Component Video Connector
S-Video Mini Din 4pin
S-Video Connector
AV OUT BNC Video Connector
AV IN BNC Video Connector
VGA OUT VGA(D-sub) mini 15pin VGA(D-sub) mini 15pin Connector
VGA IN VGA(D-sub) mini 15pin VGA(D-sub) mini 15pin Connector
AUDIO IN1 (PC Audio In) Mini Jack
Audio Connector
AUDIO IN2 RCA L/R
Audio Connector
AUDIO OUT RCA L/R
Audio output Connector
SPEAKERS OUT Jack External Speakers Connector
USB* USB Touch USB Connector
AC SWITCH
(ON) / (OFF)
MAIN POWER Main Power Switch
AC IN AC-INLET AC Connector (AC-IN)
AC OUT AC-OUTLET
AC Connector (AC-OUT)
SPEAKERS Speakers
RJ45 RJ45 RJ45 Connector
DisplayPort (DP) DisplayPort DisplayPort Connector
HDMI HDMI
HDMI Connector
DVI DVI-D 24pin DVI-D 24pin Connector
To Next Page
