English
4
Overview
1
3
67
8 9 10 11 12 13 14 15 16 17
2
4
5
1_ mini-DIN host connection
2_ DC input for optional PSU
3_ LED signal meter
4_ Main Level knob
5_ Mic/Inst Mute button / Peak meter / Mode selection button
6_ RCA line inputs
7_ Microphone/Instrument combo input
8_ Headset/Phones jack
9_ Microphone/Instrument gain control
10_ Phantom power 48V switch
11_ Loopback switch
12_ Direct monitor switch
13_ Headphones output jack
14_ Headphones level control
15_ Mic/Inst post-gain level control
16_ RCA level control
17_ Headset’s microphone gain control
