IKA RH basic - Table of Contents; Contents; Control Elements

9
EN
Contents
Page
Contents 09
Control elements 09
Declaration of Conformity 10
Warranty 10
Explication of warning symbols 10
Accessories 10
Safety instructions 11
Unpacking 12
Correct use 12
Commissioning 12
Setting the operation mode 12
Stirring function 13
Setting the safety temperature limit 13
Heating function 13
Controlling the Medium temperature limit via 13
Contact Thermometer
Assembling the stand 14
Maintenance and Cleaning 14
Error Codes (RH digital) 15
Technical data 15
Control elements
IKA
®
RH basicIKA
®
RH digital
A B
P;R O
C D
E F
I L
H G
K
J
M;N
F
Standby
A Main switch
B Adjustable safety circuit
C Rotary knob, heater
D Rotary knob, motor
E LED power
F LED heating plate
M Contact thermometer jack
N Contact plug
O Power socket
P Threaded hole for stand
R Threaded plug
A Main switch
B Adjustable safety circuit
F LED heating plate
G Button heater On/Off
H Button temperature “+“
I Button temperature “-“
J Button motor On/Off
K Button motor “+“
L Button motor “-“
M Contact thermometer jack
N Contact plug
O Power socket
P Threaded hole for stand
R Threaded plug
