FUSE
Number of cabin fuse box
No. Capacity Fuse functions Type
F1 5A Right front position lamp, left rear position lamp, left license plate lamp, right license plate lamp Mini
F2 5A Cab backlight Mini
F3 5A Left front position lamp, right rear position lamp Mini
F4 20A
Combination instrument, diagnostic instrument, automatic transmission control module, anti-theft
controller, multi-function display, hazard warning lamp switch, radio & CD player
Mini
F5 15A
Reversing lamp switch (MT), gear selector switch (AT), ABS, multi-function display, diagnostic instrument,
mode selector switch, combination instrument, brake lamp switch, anti-theft controller
Mini
F6 10A Airbag unit Mini
F7 10A Rear fog lamp Mini
F8 30A Cigar lighter Mini
F9 30A Rear window heating, rearview mirror heating, DFF indicator lamp Mini
F10 30A Left rear power window, front window relay, sunroof control module, electric rearview mirror adjustment Mini
F11 5A Front roof lamp, rear roof lamp, trunk lamp Mini
F12 20A
Front wiper, door unlocking, trunk unlocking
Mini
F13 5A Combination instrument (charging indicator lamp), radio & CD player, sunroof control module Mini
F14 20A Front wiper Mini
F15 15A Fuel pump Mini
F16 30A Right rear power window Mini
