Ikco DONG FENG H30 CROSS 2016 User Manual

83
1
WIPER COMBINATION SWITCH
Front windshield wiper switch
Stop
Intermittent wiping
Normal wiping
Quick wiping
Single-step wiping: pressing the
combination switch handle once for
one wiping operation only
Front windshield washer switch
Pull the combination switch handle
in the direction of the steering wheel
plane, and then the windshield washer
will spray washer uid and the wiper will
come to work. After stopping spraying
uid, the wiper will keep on working for
three cycles after delay.
Rear windshield wiper switch
(H30, H30 CROSS)
Rotate the
ring on the handle
forwards to the position
, and then
the rear windshield wiper will wipe
intermittently.
The wiper will stop wiping after the
handle is returned to position
.
Rear windshield washer switch
(H30, H30 CROSS)
Rotate the
ring on the handle
forwards continuously to the position
, and then the washing and wiping will be
performed at the same time; release the
handle to stop the uid spraying. Then,
when the switch returns to position
automatically, the wiper continues wiping
for three times and then automatically
switches to the intermittent wiping mode.
Note:
In freezing days, check whether the wiper
arm can move freely before using the
wiper; if there is accumulated snow or ice,
clean it at rst and then turn on the wiper.
If the wiper arm fails to move freely,
turning on the wiper switch forcibly may
damage the wiper rubber strip, motor and
others.
In non-rainy days, the wiper should be
used to spray glass washer uid, so as
to avoid glass scratch or earlier damage
of wiper rubber strip in case of dry wiping.
The glass washer uid is also required to
be sprayed when using wiper in light rain.
It is prohibited to use the washer without
washer uid.
