Headlamp
High beam
Low beam
Position lamp
Turn signal lamp
Note:
It is normal that the inner surface of
headlamp will appear a thin layer
of water vapor in some application
conditions.
BULB REPLACEMENT
High beam (H7/55W)
If the right front high-beam bulb is
broken, turn counterclockwise the dust
cover to remove it and pull out the plug,
press the head of steel clip to detach
it from the hook, and then remove and
renew the bulb. Install it in the order
reverse to the removal.
Low beam (H7/55W)
Turn the steering wheel to the limit
in the opposite of the low beam
needed to be replaced; open the
movable cover (pressing the clip
and pulling it backwards) in front of
front fender; stretch the hand forward
from the movable cover opening, turn
counterclockwise the dust cover to
remove it and pull out the plug, and
press the head of steel clip to detach
it from the hook, and then remove and
renew the bulb. Install it in the order
reverse to the removal.
Note:
The lamp bulge should be aligned
with lamp holder notch.
Have the damaged left front high
beam bulb replaced at Dongfeng
Franchise Store or IKCO authorized
representatives.
Note:
The lamp bulge should be aligned with
lamp holder notch.
