IKEA DATID Installation Instructions And Use & Care Guide

13
WIRING DIAGRAM
YL
SEL0112656
Junction Box
BK
WH
BR
BU
RD
BK
Mechanical Push Buttons
(4 buttons 3 speeds)
BR
BU
WH
RD
BK
BR (Line)
YL (Min. V)
GY (Lamps)
RD (Med. V)
BK (Max. V)
Electric Box
Chassis
RD
BK
WH
BU
WH
BR
BK
GY
YL
BU
YL-GY
YL-GY
Max. V
High V
Med. V
Min. V
Common
BR
Motor
Chassis
L
N
YL
SWITCH OPERATION
POSITION FUNCTION
Off
Lamps
Low Speed
Med Speed
High Speed
No Connection
Brown - Gray
(L - 1)
Brown - Yellow
(L - 2)
Brown - Red
(L - 3)
Brown - Black
(L - 4)
MOTOR
CHARACTERISTICS
Power Supply
Frequency
Power Absorption
240 Watts
120 VAC
60 Hz
MOTOR RESISTANCE
(Ohms)
Blue - Black
Blue - Gray
Blue - Red
Blue - White
Room Temp.
28.8
30.3
37.7
45.1
23°C
12.5 uF
YL
YL
BK
RD
WH
YL-GY
YL
WH
YL
YL
S40
Junction Box
Chassis
GND

IKEA DATID Specifications

General

Width	60 cm
Number of speeds	3
Grease filter	Yes
Material	Stainless steel
Voltage	220-240 V
Frequency	50 Hz
Type	Wall-mounted
