РУССКИЙ 13
Программа
Стадия
сушки
Natural
Dry
Доступные
опции*)
Длительность
программы
(ч:мин)**)
Расход
воды
(л/цикл)
Энергопотребление
(КВтч/цикл)
1 Eco
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
50°
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55°
2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55°
2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
3:40 8.7 0.59
2 Авто
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
50-60°
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55°
2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55°
2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3 Интенсивная
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
65°
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
2:40 17.0 1.30
4 Быстрая мойка
30’
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
50° - -
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
0:30 9.0 0.50
5 Быстрая мойка
и сушка
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
50°
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
1:20 10.0 1.10
6 Стекло
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
45°
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
1:40 12.0 1.00
7 Тихая
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
50°
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55° 2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
3:35 16.5 1.00
8 Дезинфекция
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
65°
9
ENGLISH
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE
button and within 4 seconds close the door: the timer
will begin counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of time,
press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
NaturalDry
Door opening system NaturalDry is a convection drying system
which automatically opens the door during/after drying phase to
ensure exceptional drying performance every day. Door opens at
the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is
added together with the dishwasher. To see how to mount protec-
tion foil please refer to (INSTALLATION GUIDE).
NaturalDry functionality could be disabled by the user as follows:
1. Go to the Dishwasher software menu pressing and holding
button (6 sec).
2. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button:
E – enabled d – disabled
To conrm the change and exit from the Control Menu please
press and hold
button (3 sec).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash pro-
gram
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
50°
2:45 12.0 0.92
1
Eco
2
Conventional
wash and dry
55°
2:00 15.0 1.35
3
Intensive 65° - 2:30 15.0 1.50
4
Fast 50°
-
- 0:55 11.5 1.10
5
Sanitizing 65° - 1:40 11.5 1.30
6
Pre-Wash
-
-
- 0:10 4.5 0.01
7
Self-Clean 65°
-
-
0:50 8.0 0.80
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following
address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many
factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of
load, load balancing, additional selected options and sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
-
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
1:40 12.0 1.30
9
Предварительная
мойка
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
- -
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
0:10 4.5 0.01
10 Самоочистка
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
65° - -
EN
9
To open the detergent dispenser
press button C.
Introduce the detergent into
the dry dispenser D only.
Place the amount of detergent
for pre-washing directly inside
the tub.
1. When measuring out the detergent refer to the mentioned ear-
lier information to add the proper quantity. Inside the dispenser
C there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the
program so that the best washing and drying results are always
achieved.
C
D
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2019.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programes other than the eco program are indicative only. The actual time may vary depending on many factors such as temperature
and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and
sensor calibration.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
1. ECO -
bined energy and water consumption, and that it is used to assess compliance with the EU Ecodesign legislation.
2. AUTO - For normally soiled dishes with dried food residues. Senses the level of soiling on the dishes and adjusts the program accor-
dingly. When the sensor is detecting the soil level an animation appears in the display and the cycle duration is updated.
3. INTENSIVE -
Program recommended for heavily soiled crockery, especially suitable for pans and saucepans (not to be used for delicate items).
4. FAST WASH 30’ - Program to be used for half load of lightly-soiled dishes with no dried food residues.
5. FAST WASH AND DRY
- Normally soiled crockery. Everyday cycle, that ensures optimal cleaning and drying performance in shorter time.
6. GLASS - Program for delicate items, which are more sensitive to high temperatures, for example glasses and cups.
7. SILENT -
Suitable for night-time operation of the appliance. Ensures optimal cleaning and drying performance with the lowest noise emission.
8. SANITIZING - Normally or heavily soiled crockery, with additional antibacterial wash. Can be used to perform maintenance of the
dishwasher.
9. PRE-WASH - Use to refresh crockery planned to be washed later. No detergent to be used with this program.
10. SELF-CLEAN - Program to be used to perform maintenance of the dishwasher. It cleans the interior of the appliance using hot water.
Notes:
Please note that cycle FAST WASH is dedicated for lightly soiled dishes.
Program
Drying
phase
Natural
Dry
Available
options
*)
Duration of
wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1
Eco 3:40 8.7 0.66
2
Auto
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
3
Intensive 2:40 17.0 1.30
4
Fast wash 30’
-
- 0:30 9.0 0.50
5
1:20 10.0 1.10
6
Glass 1:40 12.0 1.00
7
Silent 3:35 16.5 1.00
8
Sanitizing - 1:40 12.0 1.30
9
Pre-Wash
-
- 0:10 4.5 0.01
10
Self- Clean
-
- 0:50 9.5 0.70
0:50 9.5 0.70
Показатели программы ECO были измерены в лабораторных
условиях в соответствии с европейским стандартом EN
60436:2019.
Примечание для испытательных лабораторий: Для
получения более подробной информации об условиях
испытаний по EN отправьте электронное письмо на
указанный ниже адрес: dw_test_support@whirlpool.com
Ни одна программа не предусматривает предварительную
обработку посуды.
*) Не все опции могут использоваться одновременно.
**) Установленные значения программ, за исключением
программы Eco, носят исключительно ориентировочный
характер. Фактическое время может варьироваться в
зависимости от многих факторов, таких как температура
и давление подаваемой воды, температура в помещении,
количество моющего средства, объем и тип загрузки, баланс
загрузки, выбор дополнительных опций и калибровка
датчиков.
1. ПрограммаECOдля мытья умеренно загрязненной
посуды, является наиболее эффективной программой
по комбинированному расходу энергии и воды, что
требуется для соответствия законодательству ЕС в сфере
экодизайна.
2. АВТО - программа для посуды средней степени
загрязнения с засохшими остатками пищи.
Посудомоечная машина самостоятельно определят
степень загрязнения и адаптирует процесс мойки. Когда
датчик определяет степень загрязнения, на дисплее
возникает анимированное изображение, которое
затем сменяется скорректированным значением
длительности.
3. ИНТЕНСИВНАЯпрограмма для очень грязной посуды,
наиболее подходит для сковородок и кастрюль (не
использовать для легко повреждаемой посуды).
4. БЫСТРАЯпрограмма для ограниченного количества
посуды со средней степенью загрязненности.
Обеспечивает оптимальную эффективность очистки за
короткое время.
5. БЫСТРАЯМОЙКАИСУШКА - посуда средней
степени загрязнения. Программа для повседневного
использования, обеспечивающая качественное мытье и
высушивание за короткое время.
6. СТЕКЛО - программа для хрупкой поcуды, более
чувcтвительной к выcоким температурам, такой как
cтаканы и чашки.
7. ТИХИЙРЕЖИМ— подойдет для использования
прибора в ночное время. Обеспечивает оптимальную
эффективность очистки и высушивания при низком
уровне шума.
8. ДЕЗИНФЕКЦИЯдополнительная антибактериальная
мойка для посуды с обычной и сильной степенью
загрязнения. Можно использовать для обслуживания
посудомоечной машины.
9. ПРЕДВАРИТЕЛЬНАЯМОЙКАиспользуйте для
замачивания посуды, которую планируете помыть
позже. Эта программа не использует моющее средство.
10.САМООЧИСТКА-Программу технического
обслуживания необходимо выполнять при ПУСТОЙ
посудомоечной машине, используя специальные
моющие средства, предназначенные для обслуживания
посудомоечной машины.
Примечания: Обратите внимание, что цикл FAST WASH
предназначен для слегка загрязненных блюд.
ФУНКЦИИ выбираются непосредственным нажатием
соответствующих кнопок (см. ПАНЕЛЬ УПРАВЛЕНИЯ).
Еслифункциянесовместимасвыбраннойпрограммой
(см.ТАБЛИЦАПРОГРАММ),триждымигает
соответствующийиндикаторираздаетсязвуковой
сигнал.Опциянебудетподключена.
To Next Page
Loading...
Need help?
General
