13
• Always switch the battery off before charging it.
• The battery gets hot while charging. For safety reasons,
never cover the battery.
• Place the charger on an even surface.
• You can either charge the battery on the e-bike or removed it
from the e-bike.
Battery
Charger
1. Connect the charger to the battery and then plug in the
charger. A completely empty battery will take approximately
6 hours to fully charge.
2. When the battery is fully charged, the LED on the charger
switches from red to green. For safety reasons, unplug the
battery as soon it is fully charged.
3. Unplug the charger and then disconnect it from the battery.
24 3 1
1. Battery
2. Battery charging connector
3. Charger
4. 230V
6. BATTERY CHARGING INSTRUCTION
