15
E-bike parameters
Dimensions (L × W × H) 1865 × 1140 × 630 mm
Weight ≤ 23 kg
Maximum speed 25 km/h
Maximum load ≤ 120 kg
Wheelbase between front/rear
wheel hubs
1123 ± 5 mm
Power consumption per 1000 km 1.2 kW/h
Charger parameters
Full Charging time 6,3 hours
Input voltage 100 V - 240 V~50-60 Hz
Maximum performance 60 Watts
Control unit parameters
Low voltage protection 30 ± 0.5 Volts
Over-voltage protection 12 ± 1 Amperes
Battery parameters
Battery type Lithium-ion battery
Capacity 8.7 Ah
Battery voltage 36 Volts
Battery fuse 15Ax2 total 30A
Motor parameters
Motor type Brushless permanent magnet motor
Rated output 250 Watts
Rated voltage 36 Volts
Rated torque 6.5 Nm/40 Nm
Motor effectiveness >78%
Torque moments
Stem 14-15 Nm
Handlebar 9-10 Nm
Seat clamp 7 Nm
Pedals 25 Nm
Maximum tire pressure 40-65 PSI / 2.8-4,.5 BAR
8. TECHNICAL SPECIFICATIONS
