Connecting a guitar
amplifier* to the iKEYplus
left side: audio input right side: audio output
RCA jacks
USB device
Headphones
(Optional for monitoring
during recording process)
NOTE: BE SURE THE ACCOMPA-
NYING SWITCH IS IN THE
LN
POSITION!
*recording from a guitar amp may require alternate cables/adapters
(not included), depending on brand
Guitar Amplifier
(Connect to Line output or
record/tape output)
8
