Status Flashes RED for 0.5 seconds if a NAK is received or transmitted in
DF1 protocol or if all serial communication buffers are full.
Flashes GREEN for 0.5 seconds if Good DF1 packets are being
sent. If Characters are being received or transmitted rapidly, the
LED might appear on SOLID.
DH+ Flashes RED if a Duplicate DH+ node address is already on the
network. Flashes GREEN when soliciting for stations to create a
new network or DH+ cable is not connected. Alternately flashes
RED and GREEN if in DH+ autobaud detection mode and listening
to the network to determine the baud rate to use.
5.2.3 Off-Line Modes
The following table describes the meaning of LED patterns in the different Off-
Line modes of operation.
LED Pattern Description of Operation
DH+ and Status Offline configuration of parameters mode from the serial
menu: Solid GREEN, Rest OFF
