3.0 GW1000 Hardware Layout
This Section contains information on the physical position and purpose of the
components of the GW1000.
Top side connectors
• 3-pin power – 3.81mm pitch removable screw terminal plug
• 3-pin A-B DH+ – 5.08mm pitch removable screw terminal plug
• RJ45 Ethernet
Bottom side connectors (note: one connection is permitted at a time)
• 5-pin RS485/RS422 for CHB – 3.81mm pitch removable screw terminal plug
• 9 Pin D9M connector for CHB RS232C communications
• USB connector for CHB
Front Panel Indicators
• DH+ Status
• Serial Status
• Serial Receive (RX)
• Serial Transmit (TX)
• Ethernet Activity
• Ethernet Link
• Power
RESET and CONFIGure pushbuttons are accessible through openings in the top of the
case as depicted on product label.
