DataLink Technologies Gateways, Inc.
Website: www.datalink-networks.com Tel : (604) 632-4278 / (866) 709-6390
16
5.0 Switch and LED Indicator Functions
5.1 Switch Functions
The Reset pushbutton will perform a complete hardware reset of the GW1000. It
is identical to a complete power cycle and will cause the GW1000 to go through
its LED start-up sequence.
The Configure pushbutton takes the GW1000 out of On-Line operation mode
and allows the user to restore factory default settings.
5.2 Indicator Functions
5.2.1 Power-Up and Reset Sequence
On Power-up or after the Reset button has been pressed the GW1000 executes
a self-diagnostic check of the RAM and flash firmware. The correct LED
indicator sequence to show the GW1000 is functioning properly is as follows:
After all LEDS go out.
LED STATUS
Power Green Continuously
Serial Tx Brief green flash then off
Serial Rx Green for 3 seconds then off
Status Red for 10 seconds then Green 1 second, then off
DH+ Green 1 second, Red 1 second, then flashing green for offline,
solid green for online.
After this sequence the GW1000 goes into the On-line mode of Operation. The
LED indicators will behave in the way defined by the GW1000 model used.
Normally, all LEDS will be off waiting for communication on its channels.
5.2.2 Normal On-line Operation
The following is a description of the normal operation of the Channel LEDs on
the GW1000. Custom products operation will differ from the following:
LED Description of Operation
Power Green Indicates Power is being supplied to the GW1000.
Serial Tx, Flashes GREEN when a Character is Received or
& Serial Rx Transmitted. If Characters are being received or transmitted
rapidly, the LED might appear on SOLID.
