ILLUMINO IGNIS SMARTWIRE - Setting the Device Configuration Switches; Zone Setting; ID Setting; Settings for Switch 8

Page 4
Issue: 1.4 Author: JPB Date: 18/1/2013
Setting the device configuration switches.
All devices will need to have their zone & ID switches set as described below.
Switch 8 will depend on the type of the device.
Zone Setting
Zone Number Switch 5 Switch 6 Switch 7
1 ON ON ON
2 OFF ON ON
3 ON OFF ON
4
OFF
OFF
ON
5 ON ON OFF
6 OFF ON OFF
7 ON OFF OFF
8 OFF OFF OFF
Select the zone the device is fitted to (1 to 8). Each item on a zone has the
same zone setting
ID Setting
ID
Number
Sw 1 Sw 2 Sw 3 Sw 4 ID
Number
Sw 1 Sw 2 Sw 3 Sw 4
1 OFF ON ON ON 9 OFF ON ON OFF
2 ON OFF ON ON 10 ON OFF ON OFF
3 OFF OFF ON ON 11 OFF OFF ON OFF
4 ON ON OFF ON 12 ON ON OFF OFF
5
OFF
ON
OFF
ON
13
OFF
ON
OFF
OFF
6 ON OFF OFF ON 14 ON OFF OFF OFF
7 OFF OFF OFF ON 15 OFF OFF OFF OFF
8 ON ON ON OFF
Give the device a unique zone ID number between 1 & 15. Each item on a zone
has a different ID setting.
Settings for switch 8
Detector Type Switch 8 Position
SMARTWIRE SOUNDER FLASHER BASE – SMOKE
DETECTOR
OFF
SMARTWIRE SOUNDER FLASHER BASE – HEAT ON
