ILLUMINO IGNIS SMARTWIRE - SMARTWIRE Menu Layout; User Menu; Engineer Menu; Main Menu

Page 5
Issue: 1.4 Author: JPB Date: 18/1/2013
DETECTOR
SMARTWIRE CALL POINT ON
SMARTWIRE
SOUNDER
ON
I/O INTERFACE ON
SMARTWIRE Menu Layout
User Menu
In the user menu, you can view information for Zone contents or device status,
or look at the event log. The clock can also be adjusted from here.
Any Editing is done in the Engineer Menu.
Engineer menu
Main Menu
1.Clock 4. Device
2.Zone 5. Engineer
3.Logs
Engineer Menu 1
1. Configure Zones
2. Panel/Zone Text
3. ID Device >
Engineer Menu 2
4. Alarm Verify
5. Config Alarms
6. Misc <
Verification
1. Verify Time
2. Choose Devices
Panel/Zone Text
1. Panel
2. Zones
Misc Settings
1. Language
2. Version
3. Topology 6: Reset
Alarm Operation
1. Fire Relay
2. Interfaces
3. Alarm Tone
