11
3 Way Air/Water Syringe
Right-hand button for air (a) and the left-hand button for water (b) and both for a fine mist
(a & b).
The 3 Way Syringe is ideal for flushing away debris during prophys or drying areas during
endodontic procedures.
Tip Removal
The tip of the 3 Way Syringe may be removed for cleaning and autoclaving.
Simply depress the outer ring housing (c) and remove the tip. (See diagram below).
iM3 Dental Systems
Ultrasonic Scaler Coolant Outlet
The Ultra Sonic coolant outlet is located on the back of the control box.Page 6 #2
This outlet provides coolant under pressure for an ultrasonic scaler. Water or CLS can be
selected on the GS Deluxe.
(a)
(b)
(c)
(a) Air
(b) Water
(c) Outer Ring Housing
