iM3 GS User Manual

3
Unique Design Features
iM3 Dental Systems are designed with unique and practical features to make your work
even more satisfying and productive. Please note; some features listed below, may be
optional depending on the system you purchase.
Control Top
The Corian
®
top is a non-porous work surface which is easy to sanitize. It incorporates a groove
around the edge to prevent burs falling on the floor during procedures. The control box is made from
powder coated aluminum that won’t warp or deteriorate with age.
Color Coded System
All supply lines on iM3 dental systems are color coded to simplify service and
maintenance requirements.
Maintenance Instructions
All maintenance instructions are conveniently printed on the card hanging from the unit, or printed
on the back of the dental machine ensuring the system is kept in perfect working order.
Power Board
A four socket electric power board is conveniently located on the side of the control panel, featuring
an IEC female socket. (Optional on the GS, standard on the Deluxe)
Adjustable Stainless Steel Stand
The iM3 stand is made from high quality stainless steel and is height adjustable for work and ease
of storage. (Optional on the GS, standard on the Deluxe)
Wall Arm
An air operated approx 54”/1.50m long arm is available
Ultrasonic Scaler Coolant Outlet
The ultrasonic scaler coolant outlet is mounted conveniently on the rear of the control box, to allow
the use of the water or system to supply the coolant to your ultrasonic dental scaler.
CLS Enviro System
CLS Enviro System is an ingenious occupational health and patient safety system. CLS is designed
to help reduce the risk of atmospheric pollution and the transfer of viruses, such as FIV from patient
to patient and reduce unpleasant mouth odors. (Optional on the GS, standard on the Deluxe)
Flush System—Optional on the GS, standard on the GS Deluxe
The Flush System enables CLS at a press of a button, to enter the HS air line. The foot control
pedal is depressed after pressing the flush button, pushing the CLS into the head of the handpiece,
helping to sanitize the turbine and head of the handpiece. Excess CLS is caught in the small
collection bottle mounted underneath the control box after flushing the exhaust air line.
Particle Filters and Bacterial Filters
Particle filters and bacterial filters are installed on all iM3 dental systems to help reduce particles
entering the water supply and reduce unpleasant environmental odors from the HP exhaust collec-
tion bottles.
Options
Stainless Steel Instrument Tray
Height adjustable and mounts on the rear of the unit, standard on the Deluxe.
Oil Free Silent Hurricane Compressor
Mounts underneath the unit on the stainless steel stand—supplying air wherever the unit is to be
used, and is considered more convenient than a noisy compressor which is usually situated in an-
other room and requires a length of air line. iM3’s has produced an Oil free compressor - low main-
tenance, oil free air.
