 Recommended Separation Distances
The device is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The user can help prevent electromagnetic interference by
maintaining a minimum distance between portable and mobile FR communications
equipment (transmitters) and the device as recommended below, according to the maximum
output power of the communications equipment.
Rated maximum
output power of
transmitter‘W’
Separation distance according to the frequency of transmitter
‘m’
from 150 kHz to 80
MHz
d = 1,2 √P
from 80 MHz to 800
MHz
d = 1,2 √P
from 800 MHz to
2,5 GHz
d = 2,3 √P
0,01
0,12
0,12
0,23
0,1
0,38
0,38
0,73
1
1,2
1,2
2,3
10
3,8
3,8
7,3
100
12
12
23
For transmitters rated at a maximum output power not listed above, the recommended
separation distance d in meters (m) can be calculated using the equation applicable to the
frequency of the transmitter, where P is the maximum output power rating of the transmitter
in watts (W) according to the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
Section X: Troubleshooting
Although service and repair of the iM3 P6 system should be performed by iM3 personnel, the
following are some basic trouble shooting procedures that will help save you time and avoid
making service calls. Generally, check all lines and connections to and from the system. A
loose plug or connection will often create problems.
10-A Troubleshooting Guide
PROBLEM
POSSIBLE CAUSE
SOLUTION
The device does not
turn on when the switch
is in the “ON” position.
The power cord is not plugged
in.
Check your connection to the
outlet and the unit.
The device is turned on
but does not vibrate
when you press the foot
switch.
Tip is worn out/ not screwed in
properly. Tip is wrong style
(not Satelec-compatible).
Check the style and quality of
the tip and ensure that it is
screwed in properly by using
the enclosed torque wrench.
Replace tip if old or damaged.
