Key No. Qty. Description Key No. Qty. Description
101 1 Circuit Breaker
102 1 Power Cord
103 1 Power Cord Grommet
104 2 Caution Decal
105 6 Endcap Screw/Catch Screw
106 1 Jack
107 1 10Õ iFIT.com Audio Cable
108 4 Leaf Spring Bolt
109 2 2-pound Weight
110 4 Console Screw (short)
111 1 12Ó Audio Wire
112 1 Tension Washer
113 1 Tension Bolt
114 2 Motor Mounting Washer
115 4 Front Isolator/Spacer Cap
116 2 Leaf Spring
117 1 Cushion Adjustment Rod
118 1 Left Cushion Adj. Rack
119 1 Right Cushion Adj. Rack
120 2 Cushion Adj. Gear
121 1 Cushion Adj. Knob
122 6 Controller Screw
123 6 Gear Screw
124 4 Leaf Spring Nut
# 1 14Ó White Wire, 2 F
# 1 4Ó White Wire, M/F
# 1 4Ó Blue Wire, 2 F
# 1 8Ó Blue Wire, 2 F
# 1 8Ó Black Wire, M/F
# 1 4Ó Black Wire, 2 F
# 1 14Ó Green Wire, F/Ring
# 1 UserÕs Manual
* Includes all parts shown in the box
# These parts are not illustrated
ORDERING REPLACEMENT PARTS
To order replacement parts, call our Customer Service Department toll-free at 1-800-999-3756, Monday through
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give
the following information:
When requesting help or service, or ordering parts, please be prepared to provide the following information:
¥ The MODEL NUMBER of the product (IMTL99001)
¥ The NAME of the product (IMAGE
¨
1250 treadmill)
¥ The SERIAL NUMBER of the product (see the front cover of this manual)
¥ The KEY NUMBER AND DESCRIPTION OF THE PART (see the PART LIST at the left and above and the
EXPLODED DRAWING in the center of this manual)
If possible, place the treadmill near your telephone for easy reference when calling.
