1903KITINE18_02 (E100901B_ENG) 01/02/2016
2
INDICE:
1. INTRODUCTION .............................................. 2
2. SAFETY RULES .............................................. 2
3. MANUFACTURER’S LIABILITY ..................... 2
4. KIT COMPOSITION ......................................... 3
5. MECHANICAL INSTALLATION ...................... 3
6. ELECTRIC INSTALLATION ............................ 3
7. WORKING TEST .............................................. 4
1. INTRODUCTION
This document explains all the necessary
steps to make indipendent the drum
rotation from the fan rotation.
This kit is suitable only for tumble dryer
model ES 10/14/18 which are not
equipped with the automatic reversing
drum.
In case of big linen, drying can be difficult
because off the “ball effect” that can
cause a uneven drying of the linen. In
case of a single rotation direction of the
drum, the linen rolled up and stop the
warm air which is not arriving to the
middle.
The double rotation, on the right and on
the left side, avoid the ball effect and
assure an homogenous and rapid drying.
2. SAFETY RULES
Ignoring the following safety precautions
can cause damage either to people, linen,
animals or to the machine.
Installation and maintenance of machines
of this manual must be performed by
authorised and qualified technicians; they
have to know our products and be
acquainted with European standards for
installation of industrial laundry
equipment.
These tumble dryers must be used only
to dry garments and linen exclusively with
water. Any other use is forbidden unless
builder authorises it in writing.
It is forbidden to put anything in the
machine other than the items to be dried.
Do not load the machine with fabrics
contaminated by dangerous substances
such as explosives, inflammables, etc.
Make sure they are rinsed or aired before
washing.
It is forbidden to dry garments soaked in
substances known to be harmful to
persons such as lead, poison or cancer-
producing products
To prevent fire hazard or explosions do
not stand near the machine with
explosive or inflammable products.
Please stick accurately to instructions and
dosages recommended by
manufacturers; Make sure to check and
comply with washing instructions of each
item to be washed.
Use of the machine is forbidden to
children under 14 years of age.
The builder is not responsible for external
connections not duly performed.
These precautions do not
include all possible risks.
Therefore the user must
proceed with caution in the
observance of all safety
specifications.
3. MANUFACTURER’S LIABILITY
These manual instructions are not
intended to substitute, but only to
combine obligations of current legislation
on safety standards.
With reference to information included in
this manual, the manufacturer is not
responsible in case of:
neglect of European safety
standards during machine
utilisation;
incorrect installation of the
machine;
neglect or incorrect observance
of instructions included in this
manual;
faults of voltage or of the feeding
systems;
unauthorised changes on the
machine;
Utilisation of the machine by
unauthorised operators.
