LRX10 Laser Detector
f
g
c
i
h
a a b
d e
j
k
l
k
m
o
n
LCD Display
LRX10 Detector
a. Magnet
b. Laser Sensor Window
c. LCD Display
d. LED Grade Indicators
e. Detector Clamp
f. On/Off
g. Volume
h. Accuracy (dead
bands)/Alternate RL
i. Grade LEDs
Display
j. Numeric Digit Display
k. Grade Indication Arrows
l. On Grade Indicator
m. Beeper Volume Indicator
n. Accuracy Display
o. Battery Indicator
