17 Stem 1
Stainless steel
18 Plug 2
Stailnless steel
19 Head flange 1
Stainless steel
20 Drain valve 1
Stailnless steel
21 Screw 12
Stainless steel
(*) NBR standard material for temperature range from -20°C up to +100°C.
(**)Quantity depends on the model
Stop protection assembly for cylinder
Fig. 9 – Stop protection assembly for cylinder
Stop protection assembly part list
Item Description Qty Material Spare Parts
1 Travel stop screw 1 Carbon steel
2 Travel stop protection 1 Stainless steel
3 O-ring 1 NBR (*) #
4 Plug 1
Stainless steel
(*) NBR standard material for temperature range from -20°C up to +100°C.
