10 PARTS LIST GENERAL ASSEMBLY
This section includes the drawings and parts lists of each component and subassembly of SC/VHS
series.
Important:
When ordering spare parts, please indicate the serial number embossed on
the actuator nameplate.
Important:
When ordering spare parts, please refer to the spare part kit on the attached
drawings.
Important:
When ordering spare parts, use ONLY original STI spare parts.
