COMMANDS LEGEND (Fig.1)
A = Reduced temperature setting knob
B = Comfort temperature setting knob
C = Operating mode selector
D = Timer index
E = Programmer clock
F = Position of selectors for Comfort/Reduced temperature G = Light for low battery warning and alarms
CLOCK ADJUSTMENT
Rotate the disc of the clock clockwise positioning the indicator on the current time (Fig.1 D). Remember to
reset the clock moving from Daylight Saving Time to Standard Time and vice versa.
MODO OFF
Position the selector (Fig.1 C) on to turn off the thermostat.
In case of ambient temperature < 5°C the anti-freeze function is activated.
MANUAL OPERATION
Position the selector (Fig.1 C) on the symbol
The reduced temperature knob (Fig.1 A) Fig.1 A) and the clock (Fig.1 E) are disabled.
