1. INSTALLATION
1.1 Installation recommendations.
e CAR
V2
remote control, including the relative cables and
connections to the boiler, must be installed by specialised
sta. On the free initial check of the boiler, when the CAR
V2
remote control is inserted into the system, the Immergas
authorised aer-sales centre checks the connection to the
generator terminal board and adjusts functioning. e free
check just of the CAR
V2
remote control is not envisioned
by the Immergas authorised aer-sales centre is requested
successively to the start phase of the boiler warranty.
Important: laying of the CAR
V2
remote control cables is
excluded from the free boiler checks; it is the responsibility
of the installer company.
1.2 Installation operations.
1) Separate the xing template from the body of the CAR
V2
remote control using a screwdriver as a lever in the
relevant recess (Fig. 3). Install the CAR
V2
remote control
away from heat sources and in a suitable position to detect
the room temperature correctly (Fig. 1 and 2).
Note:
the presence on the rear of the remote control of the
pipe for electric connection cables with the boiler could
recall air from outside the establishment and interfere with
the correct detection of the room temperature (e.g.: boiler
installed outside and use of the suction hood in the kitchen).
Have the job carried out by qualied sta.
2) Install the CAR
V2
remote control using the holes made
in the rear of the same directly onto the wall (Fig. 4) or
on a recess box (Fig. 5) using the relative supplied screws.
Fig. 2
Fig. 1
OK
1,5m
NO
