Permanent timing reduction. e boiler is fitted with an
electronic timer that prevents the burner igniting too frequently
in the central heating phase.
e boiler is supplied with a timer as a standard feature, set
at 180 seconds.
Central heating ignitions timer
(continuous variation)
LED flashing
(slow)
30 seconds LED 2
55 seconds LED 3
80 seconds LED 4
105 seconds LED 5
130 seconds LED 6
155 seconds LED 7
180 seconds (Standard setting) LED 8
205 seconds LED 9
230 seconds LED 10
255 seconds LED 11
Central Heating ramp timing. e boiler supplies the maxi-
mum output set in the previous parameter.
e boiler executes an ignition ramp of about 650 seconds to
go from minimum to nominal central heating output.
Central heating ignitions timer
(continuous variation)
LED flashing
(slow)
65 seconds LED 2
130 seconds LED 3
195 seconds LED 4
260 seconds LED 5
325 seconds LED 6
390 seconds LED 7
455 seconds LED 8
520 seconds LED 9
585 seconds LED 10
650 seconds (Standard setting) LED 11
Central heating ignitions delayed due to Room thermostat
or Remote control requests. e boiler is set to turn on im-
mediately after a request.
In the case of particular systems (i.e. zone systems with mo-
torised thermostat valves, etc.) it might be necessary to delay
ignition.
Central heating ignitions delayed due to
Room thermostat or Remote control requests
(continuous variation)
LED flashing
(slow)
0 seconds (Standard setting) LED 2
57 seconds LED 3
113 seconds LED 4
170 seconds LED 5
226 seconds LED 6
283 seconds LED 7
340 seconds LED 8
396 seconds LED 9
453 seconds LED 10
510 seconds LED 11
Domestic hot water thermostat. If the “correlated” thermostat
is set the boiler switches off according to the temperature set
with the d.h.w. adjustment knob.
While if the “fixed” d.h.w. thermostat is set, switching off
temperature is set at 85°C regardless of what position the
knob is in.
Domestic hot water thermostat
LED flashing
(slow)
Correlated (Standard setting)
Led 2
Fixed
Led 11
Circulator function. Two circulator functioning modes can
be selected in the central heating phase.
In the “intermittent” mode, it is activated either by the Remote
control or eventual by the room thermostat, in the “continua-
tive” mode the circulator works all the time when the main
selector switch by Remote control is on heating.
Circulator function
LED flashing
(slow)
Intermittent (Standard setting)
LED 2
Continuous LED 11
