Gas G110 – China Gas. e setting of this function serves to
adjust the boiler to work with the gases of the first family.
Gas G110 - China Gas (first family gas)
LED flashing
(slow)
Off (Standard setting)
LED 2
On
LED 11
Relay 1 operation*.
Relay 1 operation
(switching, free contacts)
LED flashing
(slow)
Off (Standard setting)
LED 2
Main zone command
LED 3
General alarm
LED 6
Central heating phase on LED 7
External gas valve powered
LED 8
Relay 2 operation*.
Relay 2 operation (single, contacts energised
with SELV contact in series)
LED flashing
(slow)
Off (Standard setting)
LED 2
Remote filling
(not usable) LED 4
General alarm
LED 6
Central heating phase on LED 7
External gas valve powered
LED 8
Secondary zone command (from S20 on relay
card contact
LED 9
Relay 3 operation*.
Relay 3 operation
(single, free contacts)
LED flashing
(slow)
Off (Standard setting)
LED 2
Aqua Celeris system powered (not usable)
LED 5
General alarm
LED 6
Central heating phase on LED 7
External gas valve powered
LED 8
* In case of connection to the relay control board (op-
tion).
