VICTRIX PRO V2 EU
134
FLUE SYSTEMS kit for VICTRIX PRO V2 100  120  150 EU Code
Vertical terminal Ø 100 (for roof exhaust) 3.032713
Vertical ue exhaust Ø 100 (in stainless steel) 3.032714
Intake stub pipe Ø 100 (conguration B
23
) 3.033760
Fan assisted horizontal kit Ø 100 (for chimney exhaust) 3.032715
Fan assisted horizontal terminal kit Ø 100 (for wall exhaust)**
3.032716
4 extension pipes Ø 100 (0,5 m long) 3.031132
4 extension pipes Ø 100 (1 m long) 3.031373
4 extension pipes Ø 100 (2 m long) 3.032319
45° bend Ø 100 3.032195
4 87° bends Ø 100 3.032731
Separator Ø 100/100 3.032717
Concentric horizontal kit Ø 110/160 (for wall exhaust)**
3.033789
Concentric vertical kit Ø 110/160 (for roof exhaust, including valley gutter for sloped roofs) 3.033790
Extension pipe Ø 110/160 (1 m long) 3.031397
Extension pipe Ø 110/160 (2 m long) 3.031398
45° bend Ø 110/160 3.031395
87° bend Ø 110/160 3.031396
Gaskets 4 pc. Ø 100 for separate ue 3.032732
Gasket Ø 110 for concentric ue 3.015344
Clapet valve Ø 125 (for piping Ø 130) in stainless steel 3.033716
IPX5D top cover for VICTRIX PRO V2 100 - 120 EU 3.033671
IPX5D top cover for VICTRIX PRO V2 150 EU 3.033672
FLUE SYSTEMS kit for VICTRIX PRO V2 180 EU Code
Vertical terminal Ø 160 (for roof exhaust) 3.034554
Vertical ue exhaust Ø 160 (in stainless steel) 3.034555
Intake stub pipe Ø 160 (conguration B
23
) 3.034565
Fan assisted horizontal kit Ø 160 (for chimney exhaust) 3.034556
Fan assisted horizontal terminal kit Ø 160 (for wall exhaust)**
3.034557
4 extension pipes Ø 160 (0,5 m long) 3.034559
4 extension pipes Ø 160 (1 m long) 3.034560
4 extension pipes Ø 160 (2 m long) 3.034561
45° bend Ø 160 3.034562
4 90° bends Ø 160 3.034563
Separator Ø 160/160 3.035122
Ø 160 for separate ue 3.034564
IPX5D top cover for VICTRIX PRO V2 180 EU 3.033689
** Check whether wall exhaust is allowed by regulatory provisions in force and local regulations
