VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
4
2 VICTRIX PRO V2 35  55  60  68  80 EU SPECIFICATIONS
Wall-hung, sealed-chamber and fan-assisted pre-mixed con-
densing modules, high eciency with forced circulation, with
variable useful power outputs:
VICTRIX PRO V2 35 EU = 33,9 kW - 3,7 kW;
VICTRIX PRO V2 55 EU = 49,8 kW - 5,1 kW;
VICTRIX PRO V2 60 EU = 58,5 kW - 7,5 kW;
VICTRIX PRO V2 68 EU = 63,4 kW - 7,5 kW;
VICTRIX PRO V2 80 EU = 73,2 kW - 7,5 kW;
and seasonal eciency ηs 94%. ey can reach ηs 98%, if
coupled with Modulating remote control code 3.020358 and
external probe.
e generators are type-approved for installation both in
heating control unit and outside the building (with specic
protection for open-air installation), can be used in the fol-
lowing congurations:
Standard sealed chamber and fan assisted (appliance type
C
13
/C
33
) - Using the vertical or horizontal concentric and
split kits.
Open chamber and fan assisted (appliance type B
23p
/ B
33
/
B
53p
) - Specic optional intake stub pipe kit required.
e module consists of:
• total pre-mixing combustion system with steel multigas
cylindrical burner, complete with ignition electrodes and
ionisation control;
• pneumatic gas valve with double shutter;
• primary gas/water heat exchanger with casing in composite
material with air vent valve and internal stainless steel coil,
consisting of 5 elements (4+1 ue side - VICTRIX PRO V2
35 EU), of 7 elements (5+2 ue side - VICTRIX PRO V2 55
EU), of 9 elements (7+2 ue side - VICTRIX PRO V2 60 -
68 - 80 EU);
• combustion chamber in stainless steel internally insulated
using ceramic panels;
• fan for ue evacuation with electronically variable speed;
• circuit for disposal of condensate including trap and exible
drain hose;
• hydraulic unit composed of a ow manifold, primary circuit
pressure transducer, modulating circulation pump and low
power consumption;
• 4 bar system safety valve and standard draining funnel;
• water overheating safety thermostat, heat exchanger safety
thermofuse and heat exchanger safety thermostat (manual
reset);
• ue control probe
• control panel supplied with P.C.B. with microprocessor with
continuous ame modulation on heating with P.I.D. control,
modulation range 1-10;
• system ow regulation probe;
• system return regulation probe;
• heating ow temperature with factory setting between 20
and 85°C;
• ignition delay device in central heating phase, antifreeze
protection, pump anti-blocking function, chimney sweep
function;
• control panel composed of main switch, C.H. system pressure
gauge, multifunction back-lit display and 12-key push button
panel with protective sliding door;
• key setting of all functions, including antilegionella function
if coupled with remote DHW storage tank with probe;
• self-diagnosis system with digital display of the temperature,
functioning status and error codes;
• IPX5D electrical insulation level, with possibility of installa-
tion outside with additional cover (open-air);
• antifreeze protection to -5 °C as per standard (-15 °C with
relevant kit optional);
• set-up for the connection of the cascade and zone regulator
kit and of the external probe;
• set-up for connection to an external 3-way valve with 230
Vac power supply, for coupling to a separate storage tank
unit for the production of DHW;
• set-up for functioning in set conguration (up to 5 boilers
with a unique INAIL safety devices kit);
• set-up for the installation of the INAIL-approved safety stub
pipes, both in single and set conguration (up to 5 boilers);
• possibility of installation with the supporting frame kit in
"free standing" mode, which can be used to install one or
more VICTRIX PRO V2 EU units. e frame is also suitable
for outdoor open-air installation;
• possibility of installation of the generator within a cabinet
suitable for outdoor installation;
• possibility of connecting (in combination with a cascade and
zone regulator) to a remote management system for remote
management of the system (optional);
• it can be combined with the system by 80Ø mm exible
ducting (single installation).
Supplied with sample points for combustion analysis, bottom
protective metal-sheet plate and gas interception cock.
Category II appliance
2H3P
, operates with natural gas and L.P.G.
CE Marking.
It is available in the following models:
• VICTRIX PRO V2 35 EU code: 3.034431
• VICTRIX PRO V2 55 EU code: 3.033857
• VICTRIX PRO V2 60 EU code: 3.033858
• VICTRIX PRO V2 68 EU code: 3.033859
• VICTRIX PRO V2 80 EU code: 3.033860
NOTA BENE: for correct installation of the boiler the Immergas
''Green Range'' air intake/fumes exhaust kit must be used,
dedicated for the VICTRIX PRO V2 EU boiler, whether in
single or cascade (set) conguration.
