VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
71
23 DIMENSIONS AND CONNECTIONS OPTIONAL WITH VICTRIX PRO V2
35  55  60  68  80 EU KIT WITH INSTALLATION ON
SUPPORTING FRAME SET UP IN LINE UP TO A MAXIMUM OF 5 APPLIANCES
NOTE: Regarding the dimensions depicted with (*) see drawing on page 43.
