Immergas ZEUS Mini - Snap-fit couplings Ø60;100; Vertical kit Ø 80;125; Separator kit Ø 80;80; Circulating pump









 








          
             
          
          
          














      














e kit comprises:
1 - Seal (1)
1 - Female concentric flange (2)
1 - Adapter Ø 60/100 for Ø
80/125 (3)
1 - Washer(4)
1 - Aluminium tile (5)
1 - Int./Exh. concentric pipe
Ø 80/125 (6)
1 - Fixed half-shell (7)
1 - Mobile half-shell (8)
e kit comprises:
1 Seal (1)
1 - Flange seal (2)
1 - Female intake flange (3)
1 - Female exhaust flange (4)
2 - 90° bend Ø 80 (5)
1 - Intake terminal Ø 80 (6)
2 - Internal washers (7)
1 - External washer (8)
1 - Exhaust pipe Ø 80 (9)



A = Head available on third
speed setting
B = Head available on second
speed setting
C = Head available on third
speed setting with by-pass
(optional) inserted
D = Head available on second
speed setting with by-pass
(optional) inserted
e kit comprises:
1 - Seal (1)
1 - Concentric 90° bend (2)
1 - Intake/exh. concentric pipe
Ø60/100 (3)
1 - Internal washer (4)
1 - External washer (5)
Head (m H
2
O)
Flowrate (l/h)
Head (kPa)




