Chapter 7 Usage of Various Functions
7-
ేై
2) Functional Specification
Item
Specification
No. of output 1 point
Output type
Pulse
Output velocity Max 2Kpps, Min 50pps
Output pulse 0 ~ 2147483647
Execution type of the increasing/decreasing velocity Designation of acceleration
Type of the direction designation Right/opposite direction pulse output
Load power supply
DC 12V/24V
Usable range of the load power supply
DC10.2 ~ 26.4V
Maximum load current
150mA
Initiative electric current Less than 0.4A, 10ms
Maximum power dropdown under On Less than DC 0.5V
Electric current leakage under Off Less than 0.1mA
On delayed time Less than 1ms
Off delayed time Less than 1ms
1) Several points can be used for the pulse output point if they are not output at the same time. Thus it is
possible that right direction pulse is output as P040, opposite direction pulse is output as P041.
