IMO VXSM550-3 - External Dimensions: VXSM 150-1, 220-1, 400-3

Default Icon
114 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
9-9 Specifications
9
Type Standard External dimensions (mm)
applicable
motor [kW] D D1 D2 D3
VXSM 150-1 1.5 158 147 94.5 72
VXSM 220-1 2.2 158 147 94.5 72
VXSM 400-3 4.0 158 147 94.5 72
